| Place of Origin: | MADE IN CHINA |
| Brand Name: | INFINITY |
| Certification: | CE ISO |
| Model Number: | IE31 Series |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Clear sheet+sponge+wood carton |
| Delivery Time: | 20-30 days after order confirmed |
| Payment Terms: | TT PAYPAL Moneygram and so on |
| Supply Ability: | 200 sets / month |
| Features:: | Energy Saving And Consumption Reduction: Use Gas-liquid Bypass Mode To Adjust The Cooling Capacity To Achieve Constant Temperature And Humidity. Simple Operation: Programmed Color LCD Touch Controller Reference Group PID Control; Experimental Data Recordin | Temperature Recovery Time: | Within 5 Mint |
|---|---|---|---|
| Observation Window: | W300 *H400mm Observation Window Is Installed On The Box Door. Multi-layer Insulating Electric Thermal Coated Glass Can Effectively Provide Heat Preservation And Prevent Condensation. | Internal Box Size: WxHxD(mm): | 500x400x400(or Specify) |
| Heating Rate (heat Storage Area): | Up From RT To + 150℃ About 35min Is Required(or Specify) | Condenser Mode: | Air-cooled(or Specify) |
| Cooling Rate (cold Storage Area): | Down From RT To-40℃ About 55min Is Required(or Specify) | Chamber Door: | Open The Door Alone, Add The Door Frame Heating Wire At The Door Frame To Prevent Condensation At The Door Frame At Low Temperature. |
Programmable Hot Cold Shock Test Chamber with Energy Saving and Consumption Reduction
The Thermal Shock Test Chamber is designed to meet various standards, including GB/T2423.1-2001 Low Temperature Test Method, GB/T2423.2-2001, GB/T2423.22-1989 Temperature Change Test, Military Standard GJB150.3-86, Military Standard GJB150.4-86, Military Standard GJB150.5-86, GJB150.5-86 Temperature Impact Test, GJB360.7-87 Temperature Shock Test, GJB367.2-87 405 Temperature Shock Test, J/T10187-91Y73 Series Temperature Change Test Box-three Box Type, and meets the standard IEC68-2-14 Test Method N_ Temperature Change.
The Thermal Shock Test Chamber has a carton size of WxHxD(mm): 1480x1450x1950 (or specify). Its source is AC380V;50Hz;18KW(or specify). This equipment simulates the temperature and humidity changes under the condition of cold and cold impact test. It allows users to evaluate the quality of the test products by subjecting them to high and low-temperature humidity tests.
The Programmable Hot Cold Shock Test Chamber is an excellent testing equipment for various industries. It is an ideal equipment for users that want to evaluate their products' quality under extreme temperature and humidity changes.
Also known as Programmable Hot Cold Shock Test Chamber.
| Product Name | Programmable Hot Cold Shock Test Chamber |
| Temperature Range | -40℃ ～ +150℃ |
| Heating Rate | Up From RT To +150℃ About 35min Is Required(or Specify) |
| Cooling Rate | Down From RT To-40℃ About 55min Is Required(or Specify) |
| Temperature Uniformity | ≦2.0℃ |
| Specimen Holder | Stainless Steel Sample Frame 2 Layers, Adjustable Height, Bearing Weight Of 30kg / Layer |
| Features | Energy Saving and Consumption Reduction: Use Gas-liquid Bypass Mode to Adjust the Cooling Capacity to Achieve Constant Temperature and Humidity. Simple Operation: Programmed Color LCD Touch Controller Reference Group PID Control; Experimental Data Recording and Processing Mode is Flexible. High Reliability: The Key Parts are Imported Parts to Ensure the Service Life and Reliability. |
| Standards | GB/T2423.1-2001 Low Temperature Test Method; GB/T2423.2-2001; GB/T2423.22-1989 Temperature Change Test; Military Standard GJB150.3-86; Military Standard GJB150.4-86; Military Standard GJB150.5-86; GJB150.5-86 Temperature Impact Test; GJB360.7-87 Temperature Shock Test; GJB367.2-87 405 Temperature Shock Test; J/T10187-91Y73 Series Temperature Change Test Box-three Box Type; Meet the Standard IEC68-2-14_ Test Method N_ Temperature Change. |
| Carton Size (WxHxD) | 1480×1450×1950(or Specify) |
| Equipment Overview | For Users to the Whole Machine (or Parts), Electrical Appliances, Instruments, Materials, Coating, Coating for the Corresponding Climate Mutation Test, Suitable for Electrical, Electronics, Machinery Industry and Other Products, Parts, Materials, Such as High and Low Temperature, Humidity Test, Simulate the Temperature and Humidity Changes Under the Condition of Cold and Cold Impact Test, So As to Evaluate the Quality of the Test Products. |
The INFINITY IE31 Series Thermal Shock Test Chamber is a high-quality product made in China with CE and ISO certification. It has a temperature range of -40℃ ～ +150℃ and a cooling rate of about 55 minutes to reach -40℃ from room temperature in the cold storage area. This makes it a great choice for companies looking to test the durability of their products against extreme temperatures.
The thermal shock test chamber is widely used in electronics, electrical appliances, communication, instrumentation, vehicles, plastic products, metal products, food, chemicals, building materials, medical, aerospace and other fields. It is suitable for testing the thermal shock resistance of various materials and products, such as metals, plastics, ceramics, electronic components, automobile parts, and more. The programmable hot cold shock test chamber can simulate the harsh environment of rapid temperature changes, which can help manufacturers to improve product performance and reliability.
The outer wall of the thermal shock test chamber is made of high-quality carbon steel plate with an electrostatic color spray plastic treatment. The left side diameter of the box is φ 50mm hole. The inner wall is made of SUS304 # fog surface stainless steel plate, and the thermal insulation material is hard polyurethane foam thermal insulation layer + glass fiber. The carton size is 1480×1450 ×1950 mm, and the internal box size is 500x400x400 mm.
The packaging details of the thermal shock test chamber include clear sheet, sponge, and wood carton. The delivery time is 20-30 days after order confirmation, and the payment terms are TT, PayPal, Moneygram, and other options. The supply ability is 200 sets per month, and the minimum order quantity is one. The price is negotiable, depending on the specific needs of the customer.
Brand Name: INFINITY
Model Number: IE31 Series
Place of Origin: MADE IN CHINA
Certification: CE ISO
Minimum Order Quantity: 1
Price: Negotiate
Packaging Details: Clear sheet+sponge+wood carton
Delivery Time: 20-30 days after order confirmed
Payment Terms: TT PAYPAL Moneygram and so on
Supply Ability: 200 sets / month
Temperature uniformity: ≦2.0℃
Cooling rate (cold storage area): Down From RT To-40℃ About 55min Is Required (or Specify)
Internal box size: WxHxD(mm): 500x400x400 (or Specify)
Temperature recovery time: Within 5 Mint
Features: Energy Saving And Consumption Reduction: Use Gas-liquid Bypass Mode To Adjust The Cooling Capacity To Achieve Constant Temperature And Humidity. Simple Operation: Programmed Color LCD Touch Controller Reference Group PID Control; Experimental Data Recording And Processing Mode Is Flexible. High Reliability: The Key Parts Are Imported Parts To Ensure The Service Life And Reliability.
This Programmable Hot Cold Shock Test Chamber is perfect for testing the durability of your products in extreme temperature conditions. With the ability to rapidly change temperatures, this Thermal Shock Test Chamber can simulate the most extreme temperature changes. Contact us today to discuss your customization needs for the IE31 Series Programmable Hot Cold Shock Test Chamber.
Our Thermal Shock Test Chamber product comes with comprehensive technical support and services to ensure that our customers can operate and maintain the equipment at peak performance:
Our team of experts is dedicated to providing the best possible support and services to our customers. We are committed to ensuring that our Thermal Shock Test Chamber product meets the highest standards of quality and reliability.
Product Packaging:
The Thermal Shock Test Chamber will be securely packaged in a wooden crate to ensure safe transportation. The chamber will be disassembled and placed in the crate with all necessary parts and accessories. The crate will be labeled with the product name, serial number, and handling instructions for the carrier. Shipping:
The Thermal Shock Test Chamber will be shipped via a reliable carrier service. The shipping cost will be calculated based on the destination and weight of the package. The customer will be notified of the shipping details and provided with a tracking number once the product has been dispatched.
Q1: What is the brand name of this Thermal Shock Test Chamber?
A1: The brand name of this product is INFINITY.
Q2: What is the model number of this Thermal Shock Test Chamber?
A2: The model number of this product is IE31 Series.
Q3: Where is this Thermal Shock Test Chamber manufactured?
A3: This product is made in China.
Q4: What certifications does this Thermal Shock Test Chamber have?
A4: This product is certified with CE and ISO.
Q5: What is the minimum order quantity for this Thermal Shock Test Chamber?
A5: The minimum order quantity for this product is 1.
Q6: What is the price of this Thermal Shock Test Chamber?
A6: The price of this product is negotiable.
Q7: What are the packaging details of this Thermal Shock Test Chamber?
A7: The packaging details of this product include a clear sheet, sponge, and a wood carton.
Q8: What is the delivery time for this Thermal Shock Test Chamber?
A8: The delivery time for this product is 20-30 days after order confirmed.
Q9: What are the payment terms for this Thermal Shock Test Chamber?
A9: The payment terms for this product include TT, Paypal, Moneygram, and other options.
Q10: What is the supply ability of this Thermal Shock Test Chamber?
A10: The supply ability of this product is 200 sets per month.
