5 Mint Temperature Recovery Programmable Rapid Temperature Change Test Chamber ±1C

Product Description:

The Thermal Shock Test Chamber's condenser mode is air-cooled, making it an energy-efficient and cost-effective option for testing facilities. It uses non-fluorine environmental protection refrigerant R404A R23, which complies with environmental protection regulations and is safe and non-toxic. This feature ensures that the chamber is environmentally friendly and does not pose any health hazards to the testing personnel.

The Thermal Shock Test Chamber is equipped with multiple standards to ensure its accuracy and reliability. It meets the following industry standards: GB/T2423.1-2001 Low Temperature Test Method; GB/T2423.2-2001; GB/T2423.22-1989 Temperature Change Test; Military Standard GJB150.3-86; Military Standard GJB150.4-86; Military Standard GJB150.5-86; GJB150.5-86 Temperature Impact Test; GJB360.7-87 Temperature Shock Test; GJB367. 2-87 405 Temperature Shock Test; J / T10187-91Y73 Series Temperature Change Test Box-three Box Type; and meets the standard IEC68-2-14_ Test Method N_ Temperature Change. These standards ensure that the test results are accurate and reliable.

The Thermal Shock Test Chamber comes with an observation window that measures W300 *H400mm. The observation window is installed on the box door, and the multi-layer insulating electric thermal coated glass effectively provides heat preservation and prevents condensation. This feature allows the user to observe the test samples without opening the chamber, reducing the risk of contamination and test failures.

Overall, the Thermal Shock Test Chamber is a reliable and efficient Programmable Rapid Temperature Change Test Chamber designed for various industries. Its ample internal box size, air-cooled condenser mode, non-fluorine environmental protection refrigerant, and multiple industry standards make it a top choice for testing facilities. The observation window with multi-layer insulating electric thermal coated glass ensures accurate observations while preserving the test sample's integrity.

Features:

• Product Name: Thermal Shock Test Chamber
• Condenser mode: Air-cooled (or Specify)
• Features:
  • Energy Saving And Consumption Reduction: Use Gas-liquid Bypass Mode To Adjust The Cooling Capacity To Achieve Constant Temperature And Humidity.
  • Simple Operation: Programmed Color LCD Touch Controller Reference Group PID Control; Experimental Data Recording And Processing Mode Is Flexible.
  • High Reliability: The Key Parts Are Imported Parts To Ensure The Service Life And Reliability.
• Chamber door: Open The Door Alone, Add The Door Frame Heating Wire At The Door Frame To Prevent Condensation At The Door Frame At Low Temperature.
• Equipment overview: For Users To The Whole Machine (or Parts), Electrical Appliances, Instruments, Materials, Coating, Coating For The Corresponding Climate Mutation Test, Suitable For Electrical, Electronics, Machinery Industry And Other Products, Parts, Materials, Such As High And Low Temperature, Humidity Test, Simulate The Temperature And Humidity Changes Under The Condition Of Cold And Cold Impact Test, So As To Evaluate The Quality Of The Test Products.

Technical Parameters:

Applications:

The INFINITY IE31 Series Thermal Shock Test Chamber is a programmable rapid temperature change test chamber, designed to test the durability and reliability of various products and materials under extreme temperature changes. This thermal shock test chamber is made in China and complies with CE and ISO certifications.

With a minimum order quantity of 1, the price of this thermal shock test chamber is negotiable, and it comes with clear sheet+sponge+wood carton packaging. The delivery time for this product is 20-30 days after order confirmation, and the payment terms accepted include TT, PayPal, Moneygram, and more. The supply ability of this product is 200 sets per month, making it easily accessible.

The IE31 Series Thermal Shock Test Chamber uses non-fluorine environmental protection refrigerants R404A and R23, which comply with environmental protection regulations and are safe and non-toxic. The heating rate from the heat storage area is up from RT to +150℃, and it requires about 35 minutes or can be specified. The thermal insulation chamber features high-quality carbon steel plate for the outer wall material, with the surface electrostatic color spray plastic treatment. The left side diameter of the box is φ 50mm hole, while the inner wall material is SUS304 # fog surface stainless steel plate. The thermal insulation material is hard polyurethane foam thermal insulation layer + glass fiber, ensuring temperature uniformity of ≦2.0℃.

The safety protection device for this thermal shock test chamber includes heater air defense incineration protection, heater over-current protection, circulation fan over-current overload protection, compressor high-pressure protection, compressor overheating protection, compressor over-current protection, over-voltage under reverse phase protection, circuit breaker, and leakage protection. All these safety measures ensure the product is safe to use.

The IE31 Series Thermal Shock Test Chamber is suitable for various product application occasions and scenarios. It can be used to test the reliability of electronic components, plastic products, metal materials, chemical materials, and many more. This thermal shock test chamber is ideal for research and development, quality control, and production line testing, among others.

Customization:

Product Description:

• Place of Origin: MADE IN CHINA
• Certification: CE ISO
• Minimum Order Quantity: 1
• Price: Negotiate
• Packaging Details: Clear sheet+sponge+wood carton
• Delivery Time: 20-30 days after order confirmed
• Payment Terms: TT PAYPAL Moneygram and so on
• Supply Ability: 200 sets / month
• Temperature range: -40℃ ～ +150℃
• Temperature uniformity: ≦2.0℃
• Refrigeration compressor: France Tecumseh Fully Closed Compressor (or Specify)
• Temperature fluctuation: ±1℃
• Internal box size: WxHxD(mm): 500x400x400 (or Specify)

The IE31 Series Thermal Shock Test Chamber is a Programmable Rapid Temperature Change Test Chamber suitable for testing the performance of various materials and products at high and low temperatures. With a temperature range of -40℃ to +150℃, temperature uniformity of ≦2.0℃, and temperature fluctuation of ±1℃, this chamber is perfect for simulating harsh environments and extreme temperature changes. The refrigeration compressor is a France Tecumseh Fully Closed Compressor (or Specify), ensuring reliable and stable performance. The internal box size is WxHxD(mm): 500x400x400 (or Specify), providing ample space for testing multiple samples at once. Contact us to negotiate the price and for more information on how to customize the Thermal Shock Test Chamber to fit your specific needs.

Support and Services:

Our Thermal Shock Test Chamber is designed to subject products to rapid temperature changes, simulating real-world conditions and stress. Our team of technical support professionals is available to assist with any questions or issues that may arise during the installation, operation, or maintenance of the chamber.

Our services include on-site installation and training, remote technical support, and preventative maintenance programs to ensure the longevity and optimal performance of your Thermal Shock Test Chamber. Additionally, we offer calibration and certification services to maintain accuracy and compliance with industry standards.

Packing and Shipping:

Product Packaging:

• The Thermal Shock Test Chamber will be packed securely in a wooden crate to ensure safe transportation.
• The crate will be labeled with the product name, model number, and any necessary handling instructions.
• All necessary documentation, including the user manual and warranty information, will be included inside the crate.

Shipping:

• The Thermal Shock Test Chamber will be shipped via a trusted and reliable carrier.
• Shipping costs will be calculated and added to the final invoice.
• The estimated shipping time will be provided once the order is confirmed.
• A tracking number will be provided so the customer can track their package during transit.

FAQ:

Q: What is the brand name of this Thermal Shock Test Chamber?

A: The brand name of this product is INFINITY.

Q: What is the model number of this Thermal Shock Test Chamber?

A: The model number of this product is IE31 Series.

Q: Where is this Thermal Shock Test Chamber made?

A: This product is made in China.

Q: What certifications does this Thermal Shock Test Chamber have?

A: This product is certified with CE and ISO.

Q: What is the minimum order quantity for this Thermal Shock Test Chamber?

A: The minimum order quantity for this product is 1.

Q: What is the price of this Thermal Shock Test Chamber?

A: The price of this product is negotiable.

Q: What are the packaging details for this Thermal Shock Test Chamber?

A: The packaging details for this product are clear sheet+sponge+wood carton.

Q: What is the delivery time for this Thermal Shock Test Chamber?

A: The delivery time for this product is 20-30 days after order confirmed.

Q: What are the payment terms for this Thermal Shock Test Chamber?

A: The payment terms for this product are TT, PayPal, Moneygram, and so on.

Q: What is the supply ability of this Thermal Shock Test Chamber?

A: The supply ability of this product is 200 sets/month.
