| Place of Origin: | MADE IN CHINA |
| Brand Name: | INFINITY |
| Certification: | CE ISO |
| Model Number: | IE31 Series |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Clear sheet+sponge+wood carton |
| Delivery Time: | 20-30 days after order confirmed |
| Payment Terms: | TT PAYPAL Moneygram and so on |
| Supply Ability: | 200 sets / month |
| Temperature Recovery Time: | Within 5 Mint | Chamber Door: | Open The Door Alone, Add The Door Frame Heating Wire At The Door Frame To Prevent Condensation At The Door Frame At Low Temperature. |
|---|---|---|---|
| Product Name: | Programmed Cold And Hot Impact Test Chamber | Temperature Range: | -40℃ ～ +150℃ |
| Cooling Rate (cold Storage Area): | Down From RT To-40℃ About 55min Is Required(or Specify) | Thermal Insulation Chamber: | ● Outer Wall Material: High Quality Carbon Steel Plate, The Surface For Electrostatic Color Spray Plastic Treatment. The Left Side Diameter Of The Box Is φ 50mm Hole ● Inner Wall Material: SUS304 # Fog Surface Stainless Steel Plate. ● Thermal Insulation Ma |
| Internal Box Size: WxHxD(mm): | 500x400x400(or Specify) | Equipment Overview:: | For Users To The Whole Machine (or Parts), Electrical Appliances, Instruments, Materials, Coating, Coating For The Corresponding Climate Mutation Test, Suitable For Electrical, Electronics, Machinery Industry And Other Products, Parts, Materials, Such As H |
The temperature recovery time of this Programmable Rapid Temperature Change Test Chamber is within 5 minutes, providing you with quick and efficient results. With a cooling rate of down from RT to -40℃, about 55 minutes is required, allowing you to perform multiple tests within a short period. The chamber's cooling rate is optimized to ensure that the cold storage area reaches the desired temperature quickly and efficiently.
The observation window of this Programmable Rapid Temperature Change Test Chamber is W300 *H400mm, providing you with a clear view of the test sample. The Multi-layer Insulating Electric Thermal Coated Glass effectively provides heat preservation and prevents condensation, ensuring the accuracy of your test results. This Thermal Shock Test Chamber is designed with your convenience in mind, allowing you to monitor the test sample without opening the chamber door, preventing temperature fluctuations and ensuring accurate results.
The source of this Programmable Rapid Temperature Change Test Chamber is AC380V;50Hz;18KW, ensuring optimal power supply for optimal results. This Thermal Shock Test Chamber is designed to provide you with reliable results that you can trust. Whether you're performing a single test or running multiple tests, this Programmable Rapid Temperature Change Test Chamber can handle it all.
| Internal box size: WxHxD(mm) | 500x400x400(or Specify) |
| Features | Energy Saving And Consumption Reduction: Use Gas-liquid Bypass Mode To Adjust The Cooling Capacity To Achieve Constant Temperature And Humidity. Simple Operation: Programmed Color LCD Touch Controller Reference Group PID Control; Experimental Data Recording And Processing Mode Is Flexible. High Reliability: The Key Parts Are Imported Parts To Ensure The Service Life And Reliability. |
| Temperature uniformity | ≦2.0℃ |
| Source | Source AC380V;50Hz;18KW(or Specify) |
| Carton size: WxHxD(mm) | 1480×1450 ×1950(or Specify) |
| Standards | GB/T2423.1-2001 Low Temperature Test Method; GB/T2423.2-2001; GB/T2423.22-1989 Temperature Change Test; Military Standard GJB150.3-86; Military Standard GJB150.4-86; Military Standard GJB150.5-86; GJB150.5-86 Temperature Impact Test; GJB360.7-87 Temperature Shock Test; GJB367. 2-87 405 Temperature Shock Test; J / T10187-91Y73 Series Temperature Change Test Box-three Box Type; Meet The Standard IEC68-2-14_ Test Method N_ Temperature Change. |
| Cooling medium | Non-fluorine Environmental Protection Refrigerant R404A R23 Comply With Environmental Protection Regulations, Safe And Non-toxic |
| Equipment overview | For Users To The Whole Machine (or Parts), Electrical Appliances, Instruments, Materials, Coating, Coating For The Corresponding Climate Mutation Test, Suitable For Electrical, Electronics, Machinery Industry And Other Products, Parts, Materials, Such As High And Low Temperature, Humidity Test, Simulate The Temperature And Humidity Changes Under The Condition Of Cold And Cold Impact Test, So As To Evaluate The Quality Of The Test Products. |
| Safety protection device | Heater Air Defense Incineration Protection; Heater Over Current Protection; Circulation Fan Over Current Overload Protection; Compressor High Pressure Protection;. Compressor Overheating Protection; Compressor Over Current Protection; Over Voltage Under Reverse Phase Protection; Circuit Breaker; Leakage Protection. |
| Thermal insulation chamber | ● Outer Wall Material: High Quality Carbon Steel Plate, The Surface For Electrostatic Color Spray Plastic Treatment. The Left Side Diameter Of The Box Is φ 50mm Hole ● Inner Wall Material: SUS304 # Fog Surface Stainless Steel Plate. ● Thermal Insulation Material: Hard Polyurethane Foam Thermal Insulation Layer + Glass Fiber. |
The Thermal Shock Test Chamber is a programmable rapid temperature change test chamber that is suitable for a variety of product application occasions and scenarios. The specimen holder of the chamber is a stainless steel sample frame with 2 layers, adjustable height, and bearing weight of 30kg per layer. The heating rate of the product is up from RT to +150℃, and about 35 minutes is required (or specify) for the heat storage area. The chamber door can be opened alone and has a door frame heating wire at the door frame to prevent condensation at the door frame at low temperature. The refrigeration compressor of the product is a France Tecumseh fully-closed compressor (or specify).
The Thermal Shock Test Chamber features energy saving and consumption reduction by using a gas-liquid bypass mode to adjust the cooling capacity to achieve constant temperature and humidity. The product has simple operation with a programmed color LCD touch controller reference group PID control. The experimental data recording and processing mode is flexible. The product has high reliability due to its key parts being imported parts to ensure service life and reliability.
The Thermal Shock Test Chamber is suitable for a variety of product application occasions and scenarios, including but not limited to:
The packaging details of the Thermal Shock Test Chamber include a clear sheet, sponge, and wood carton. The product is a reliable and efficient way to test the effects of temperature changes on products and components.
Introducing the INFINITY IE31 Series Programmable Rapid Temperature Change Test Chamber, an exceptional Thermal Shock Test Chamber made in China that is certified by CE and ISO. This high-quality equipment is suitable for the electrical, electronics, machinery industry and other products, parts, materials, such as high and low temperature, humidity test, simulate the temperature and humidity changes under the condition of cold and cold impact test, so as to evaluate the quality of the test products.
Our Thermal Shock Test Chamber's cooling medium uses a Non-fluorine Environmental Protection Refrigerant R404A R23 Comply With Environmental Protection Regulations, Safe And Non-toxic. It also has Energy Saving And Consumption Reduction capabilities, with a gas-liquid bypass mode to adjust the cooling capacity to achieve constant temperature and humidity. The Programmable Rapid Temperature Change Test Chamber is easy to operate with a programmed color LCD touch controller reference group PID control, and the experimental data recording and processing mode is flexible. Its key parts are imported parts to ensure the service life and reliability, making it a high-reliability equipment.
We offer customization services that include the following attributes:
Our Thermal Shock Test Chamber product is designed to test the ability of materials to withstand sudden changes in temperature.
Our skilled product technical support team is available to provide assistance with installation, setup, and operation of the chamber. We offer comprehensive training to ensure that customers are able to use the chamber safely and effectively.
In addition to technical support, we also offer a range of services to help customers get the most out of their Thermal Shock Test Chamber. These services include calibration, maintenance, and repair. Our team of experienced technicians can quickly diagnose and repair any issues that arise, minimizing downtime and maximizing productivity.
At our company, we are committed to providing exceptional customer service and support for all of our products, including the Thermal Shock Test Chamber.
Product Packaging:
Shipping:
Q: What is the brand name of this product?
A: The brand name of this product is INFINITY.
Q: What is the model number of this product?
A: The model number of this product is IE31 Series.
Q: Where is this product made?
A: This product is made in China.
Q: What certifications does this product have?
A: This product has CE and ISO certifications.
Q: What is the minimum order quantity for this product?
A: The minimum order quantity for this product is 1 set.
Q: What is the price of this product?
A: The price of this product is negotiable.
Q: What are the packaging details for this product?
A: The packaging details for this product include a clear sheet, sponge, and wood carton.
Q: What is the delivery time for this product?
A: The delivery time for this product is 20-30 days after order confirmed.
Q: What are the payment terms for this product?
A: The payment terms for this product include TT, PayPal, Moneygram, and other options.
Q: What is the supply ability of this product?
A: The supply ability of this product is 200 sets per month.
