| Place of Origin: | MADE IN CHINA |
| Brand Name: | INFINITY |
| Certification: | CE ISO |
| Model Number: | IE31 Series |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Clear sheet+sponge+wood carton |
| Delivery Time: | 20-30 days after order confirmed |
| Payment Terms: | TT PAYPAL Moneygram and so on |
| Supply Ability: | 200 sets / month |
| Temperature Recovery Time: | Within 5 Mint | Temperature Fluctuation: | ±1℃ |
|---|---|---|---|
| Thermal Insulation Chamber: | ● Outer Wall Material: High Quality Carbon Steel Plate, The Surface For Electrostatic Color Spray Plastic Treatment. The Left Side Diameter Of The Box Is φ 50mm Hole ● Inner Wall Material: SUS304 # Fog Surface Stainless Steel Plate. ● Thermal Insulation Ma | Chamber Door: | Open The Door Alone, Add The Door Frame Heating Wire At The Door Frame To Prevent Condensation At The Door Frame At Low Temperature. |
| Specimen Holder: | Stainless Steel Sample Frame 2 Layers, Adjustable Height, Bearing Weight Of 30kg / Layer. | Cooling Rate (cold Storage Area): | Down From RT To-40℃ About 55min Is Required(or Specify) |
| Heating Rate (heat Storage Area): | Up From RT To + 150℃ About 35min Is Required(or Specify) | Temperature Uniformity: | ≦2.0℃ |
The Thermal Shock Test Chamber uses non-fluorine environmental protection refrigerant R404A R23 that complies with environmental protection regulations and is safe and non-toxic as the cooling medium. The device has a thermal insulation chamber that is made of high-quality carbon steel plate with the surface coated with electrostatic color spray plastic treatment. The left side diameter of the box is φ 50mm hole. The inner wall of the chamber is made of SUS304 # fog surface stainless steel plate, and the thermal insulation material comprises of hard polyurethane foam thermal insulation layer and glass fiber.
The device has a heating rate (heat storage area) of up from RT to + 150℃, which requires about 35min (or specify) for the temperature to reach the desired level. The thermal shock test chamber has a specimen holder that is made of stainless steel sample frame 2 layers, adjustable height, and bearing weight of 30kg / layer.
The Thermal Shock Test Chamber is perfect for use in industries such as electronics, aerospace, automotive, medical, and military. It is a highly reliable and efficient device that can simulate the environmental conditions that materials and products will be subjected to in real-life conditions. This device is an excellent investment for companies that want to test their products' durability and reliability before launching them into the market.
| Product Name | Thermal Shock Test Chamber |
| Standards | GB/T2423.1-2001 Low Temperature Test Method; GB/T2423.2-2001; GB/T2423.22-1989 Temperature Change Test; Military Standard GJB150.3-86; Military Standard GJB150.4-86; Military Standard GJB150.5-86; GJB150.5-86 Temperature Impact Test; GJB360.7-87 Temperature Shock Test; GJB367. 2-87 405 Temperature Shock Test; J / T10187-91Y73 Series Temperature Change Test Box-three Box Type; Meet The Standard IEC68-2-14_ Test Method N_ Temperature Change |
| Temperature Fluctuation | ±1℃ |
| Safety Protection Device | Heater Air Defense Incineration Protection; Heater Over Current Protection; Circulation Fan Over Current Overload Protection; Compressor High Pressure Protection;. Compressor Overheating Protection; Compressor Over Current Protection; Over Voltage Under Reverse Phase Protection; Circuit Breaker; Leakage Protection |
| Equipment Overview | For Users To The Whole Machine (or Parts), Electrical Appliances, Instruments, Materials, Coating, Coating For The Corresponding Climate Mutation Test, Suitable For Electrical, Electronics, Machinery Industry And Other Products, Parts, Materials, Such As High And Low Temperature, Humidity Test, Simulate The Temperature And Humidity Changes Under The Condition Of Cold And Cold Impact Test, So As To Evaluate The Quality Of The Test Products |
| Cooling Medium | Non-fluorine Environmental Protection Refrigerant R404A R23 Comply With Environmental Protection Regulations, Safe And Non-toxic |
| Features | Energy Saving And Consumption Reduction: Use Gas-liquid Bypass Mode To Adjust The Cooling Capacity To Achieve Constant Temperature And Humidity. Simple Operation: Programmed Color LCD Touch Controller Reference Group PID Control; Experimental Data Recording And Processing Mode Is Flexible. High Reliability: The Key Parts Are Imported Parts To Ensure The Service Life And Reliability |
| Carton Size | WxHxD(mm): 1480×1450×1950(or Specify) |
| Condenser Mode | Air-cooled(or Specify) |
| Source | Source AC380V;50Hz;18KW(or Specify) |
| Refrigeration Compressor | France Tecumseh Fully Closed Compressor(or Specify) |
The INFINITY IE31 Series Thermal Shock Test Chamber is a highly efficient and reliable product that is made in China and has been certified by CE and ISO. It is designed for various environmental simulation tests and is suitable for use in laboratories, research institutions and manufacturing plants. The minimum order quantity for this product is 1, and the price can be negotiated. The packaging details include clear sheet+sponge+wood carton, and the delivery time is 20-30 days after order confirmation. Payment terms accepted include TT, PayPal, Moneygram, among others. The supply ability is 200 sets per month.
This Programmable Rapid Temperature Change Test Chamber is equipped with several safety protection devices, such as Heater Air Defense Incineration Protection, Heater Over Current Protection, Circulation Fan Over Current Overload Protection, Compressor High Pressure Protection, Compressor Overheating Protection, Compressor Over Current Protection, Over Voltage Under Reverse Phase Protection, Circuit Breaker, Leakage Protection, etc. These devices ensure the safety of the users and the product itself.
The internal box size of the Thermal Shock Test Chamber is WxHxD(mm): 500x400x400(or Specify), and the temperature range is -40℃ ～ +150℃. It can perform various environmental simulation tests, including low-temperature tests, temperature change tests, temperature impact tests, etc. This Programmable Rapid Temperature Change Test Chamber meets several standards such as GB/T2423.1-2001 Low Temperature Test Method, GB/T2423.2-2001, GB/T2423.22-1989 Temperature Change Test, Military Standard GJB150.3-86, Military Standard GJB150.4-86, Military Standard GJB150.5-86, GJB150.5-86 Temperature Impact Test, GJB360.7-87 Temperature Shock Test, GJB367. 2-87 405 Temperature Shock Test, J / T10187-91Y73 Series Temperature Change Test Box-three Box Type, Meet The Standard IEC68-2-14_ Test Method N_ Temperature Change.
Customize your INFINITY IE31 Series Programmable Rapid Temperature Change Test Chamber, also known as Thermal Shock Test Chamber, to fit your specific needs. This product is made in China and has CE and ISO certification.
The minimum order quantity is 1, and the price is negotiable. The packaging details include clear sheet, sponge, and wood carton. The delivery time is 20-30 days after order confirmation. Payment terms accepted include TT, PayPal, Moneygram, and others. The supply ability is 200 sets per month.
The condenser mode is air-cooled (or specify your preference). An observation window (W300 *H400mm) is installed on the box door. The multi-layer insulating electric thermal coated glass can effectively provide heat preservation and prevent condensation. The heating rate (heat storage area) is up from RT to + 150℃ and requires about 35 minutes (or specify your preference).
The thermal insulation chamber includes an outer wall made of high quality carbon steel plate, with the surface electrostatically color spray plastic treated. The left side diameter of the box is φ 50mm hole. The inner wall material is SUS304 # fog surface stainless steel plate. The thermal insulation material includes hard polyurethane foam thermal insulation layer and glass fiber. The temperature uniformity is ≦2.0℃.
The Thermal Shock Test Chamber is designed to simulate rapid temperature changes and extreme thermal environments for testing the reliability and durability of various materials and products. Our technical support and services include:
- Installation and setup assistance
- Operation guidance and training
- Troubleshooting and repair services
- Calibration and maintenance services
- Customization options to meet specific testing requirements
Our experienced team is dedicated to providing excellent customer service and ensuring the optimal performance of your Thermal Shock Test Chamber.
Product Packaging:
The Thermal Shock Test Chamber will be securely packaged in a wooden crate to ensure safe transportation. The crate will be lined with foam to prevent any damage to the chamber during shipping.
Shipping:
The Thermal Shock Test Chamber will be shipped via a reliable freight carrier. The shipping costs will be calculated based on the destination and weight of the package. The estimated shipping time will be provided to the customer upon purchase. Please note that additional customs fees may apply for international shipments.
Q: What is the brand name of the Thermal Shock Test Chamber product?
A: The brand name of the Thermal Shock Test Chamber product is INFINITY.
Q: What is the model number of the Thermal Shock Test Chamber product?
A: The model number of the Thermal Shock Test Chamber product is IE31 Series.
Q: Where is the Thermal Shock Test Chamber product made?
A: The Thermal Shock Test Chamber product is made in China.
Q: What certifications does the Thermal Shock Test Chamber product have?
A: The Thermal Shock Test Chamber product has CE and ISO certifications.
Q: What is the packaging details for the Thermal Shock Test Chamber product?
A: The packaging details for the Thermal Shock Test Chamber product are clear sheet+sponge+wood carton.
Q: What is the delivery time for the Thermal Shock Test Chamber product?
A: The delivery time for the Thermal Shock Test Chamber product is 20-30 days after order confirmed.
Q: What are the payment terms for the Thermal Shock Test Chamber product?
A: The payment terms for the Thermal Shock Test Chamber product are TT, PayPal, Moneygram and so on.
Q: What is the minimum order quantity for the Thermal Shock Test Chamber product?
A: The minimum order quantity for the Thermal Shock Test Chamber product is 1.
Q: What is the supply ability for the Thermal Shock Test Chamber product?
A: The supply ability for the Thermal Shock Test Chamber product is 200 sets per month.
Q: How can I negotiate the price for the Thermal Shock Test Chamber product?
A: Please contact our sales team to negotiate the price for the Thermal Shock Test Chamber product.
