| Place of Origin: | MADE IN CHINA |
| Brand Name: | INFINITY |
| Certification: | CE ISO |
| Model Number: | IE10A1 |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Clear sheet+sponge+wood carton |
| Delivery Time: | 20-30 days after order confirmed |
| Payment Terms: | TT PAYPAL Moneygram and so on |
| Supply Ability: | 200 sets / month |
| Features: | Energy Saving And Consumption Reduction: Use Gas-liquid Bypass Mode To Adjust The Cooling Capacity To Achieve Constant Temperature And Humidity. Easy To Operate: Programmable Color LCD Touch Controller Includes PID Control; Experimental Data Recording An | Sample Holder: | Stainless Steel Sample Rack 2 Layers, Height Adjustable, Bearing Weight 30kg/ Layer. |
|---|---|---|---|
| Equipment Overview: | This Series Of Constant Temperature And Humidity Box Is Suitable For Environmental Simulation Reliability Test Of Industrial Products, With The Characteristics Of Temperature And Humidity Control Accuracy And Wide Control Range, And The Performance Indicat | Coolants: | Non-fluorine Environmental Refrigerant R404A, In Line With Environmental Regulations, Safe And Non-toxic |
| Condenser System: | Air-cooled | Product Name: | Programmable Constant Temperature And Humidity Test Chamber |
| Heating Rate: | From -20℃ Up To +100℃ Within 40min (When Unloaded, The Ambient Temperature Is +25℃) | Humidity Fluctuation: | ±1.0％RH |
Warm-keeping Box Constant Temperature Humidity Test Chamber for Mechanical Products
The Programmable Constant Temperature And Humidity Test Chamber is a highly advanced environmental test chamber designed for precise and accurate testing of temperature and humidity conditions. It is widely used in various industries such as electronics, automotive, aerospace, and pharmaceuticals to test the reliability and performance of products under different environmental conditions.
The Programmable Constant Temperature And Humidity Test Chamber offers exceptional humidity uniformity of ±3.0％RH (no load), ensuring consistent and accurate testing results. This feature makes it suitable for various applications that require precise humidity control.
This environmental test chamber has a wide temperature range of -20℃ ～ +150℃, allowing for testing under extreme temperature conditions. The temperature can be easily controlled and programmed according to the specific testing requirements.
The humidity deviation of this test chamber is ±3.0％RH (>75％RH) and ±5.0％RH (≤75％RH), making it ideal for testing products that are sensitive to humidity changes. With this feature, you can ensure accurate and reliable testing results for your products.
The Programmable Constant Temperature And Humidity Test Chamber uses non-fluorine environmental refrigerant R404A, which is in line with environmental regulations. This refrigerant is safe and non-toxic, making it an eco-friendly option for your testing needs.
The Programmable Constant Temperature And Humidity Test Chamber is a highly efficient and reliable equipment for testing the impact of temperature and humidity on products. With its advanced features and precise control, it is an essential tool for industries that require accurate environmental testing.
IE10A1
MADE IN CHINA
CE, ISO
1
Negotiate
Clear sheet+sponge+wood carton
20-30 days after order confirmed
TT, PAYPAL, Moneygram, and so on
200 sets / month
For a single door, install a heating wire in the door frame to prevent condensation in the door frame at low temperature.
This series of constant temperature and humidity box is suitable for environmental simulation reliability test of industrial products, with the characteristics of temperature and humidity control accuracy and wide control range, and the performance indicators meet the requirements of GB5170.2.3.5.6-95.
| Model | IE10A1 150L | IE10A1 225L | IE10A1 408L | IE10A1 800L | IE10A1 1000L | |||||
| Temp. range | -20℃ ～ +150℃ | |||||||||
| Temp. fluctuation | ±0.5℃ | |||||||||
|
Temp. uniformity
|
≦2.0℃ | |||||||||
| Heating rate | from -20℃ up to +100℃ within 40min (No load, ambient temperature +25℃) | |||||||||
| Temp.decrease rate | from +20℃ down to -20℃ within 40min (No load, ambient temperature +25℃) | |||||||||
| Humidity control range | 20%R.H～98%R.H | |||||||||
| Humidity deviation |
±3.0％RH(＞75％RH) ±5.0％RH(≤75％RH) |
|||||||||
| Humidity evenness | ±3.0％RH (no-load test) | |||||||||
| Humidity fluctuation | ±1.0％RH | |||||||||
|
Inner box size WxHxD(mm) |
500x600x500 | 500x750x600 | 600×850×800 | 1000×1000×800 | 1000×1000×1000 | |||||
|
Outside box size WxHxD(mm) |
720×1500×1270 | 720×1650×1370 | 820×1750 ×1580 | 1220×1940 ×1620 | 1220×1940 ×1820 | |||||
| Fluid Warmers |
● Outer wall material: high quality carbon steel plate, surface for electrostatic color spray treatment. The left side of the box is φ50mm diameter hole ● Inner wall material :SUS304# stainless steel plate. ● Insulation material: hard polyurethane foam insulation layer + glass fiber. |
|||||||||
| Door | For a single door, install a heating wire in the door frame to prevent condensation in the door frame at low temperature. | |||||||||
| Inspection window | The W 300×H 400mm observation window is installed on the door of the box, and multi-layer hollow electrothermal coated glass can effectively keep heat and prevent condensation. | |||||||||
| Lighting device | 1 set LED lighting device, installed on the window. | |||||||||
| Sample holder | Stainless steel sample rack 2 layers, height adjustable, bearing weight 30kg/ layer. | |||||||||
| Refrigeration compressor | France Tecumseh fully closed compressor | |||||||||
| Refrigerant | Non-fluorine environmental refrigerant R404A, in line with environmental regulations, safe and non-toxic | |||||||||
| Condenser system | air-cooled | |||||||||
| Safety protection device |
Heater anti-burning protection; Humidifier anti-burn protection; Heater overcurrent protection; Humidifier overcurrent protection; Circulating fan overcurrent overload protection; Compressor high pressure protection; Compressor overheat protection; Compressor overcurrent protection; Overvoltage underinverse-phase protection; Circuit breaker; Leakage protection; Humidifier low water level protection; Tank low water level warning. |
|||||||||
| Power supply | AC220V;50Hz;4.5KW | AC380;V50Hz;6KW | AC380;V50Hz;7KW | AC380;V50Hz;9KW | AC380;V50Hz;11KW | |||||
Brand Name: INFINITY
Model Number: IE10A1
Place of Origin: MADE IN CHINA
Certification: CE, ISO
Minimum Order Quantity: 1
Price: Negotiate
Packaging Details: Clear sheet+sponge+wood carton
Delivery Time: 20-30 days after order confirmed
Payment Terms: TT, PAYPAL, Moneygram and so on
Supply Ability: 200 sets / month
Climate Test Chamber: The INFINITY IE10A1 is a top-of-the-line climate test chamber, designed to provide precise and accurate temperature and humidity control for various testing applications.
Programmable Constant Temperature and Humidity: With advanced programmable control system, the IE10A1 allows users to set and adjust temperature and humidity levels according to their specific testing requirements.
Customized Service: INFINITY offers customized services to meet the unique needs and specifications of our customers. From special sizes to specific functions, we can tailor the IE10A1 to fit your testing needs.
Whether you need a larger chamber for bigger test samples or a specialized lighting device, our team of experts will work with you to create a custom solution that meets your exact requirements.
The constant temperature and humidity test chamber is carefully packed with foam and plastic film to ensure its safety during transportation. It is then placed in a sturdy wooden case for added protection. The package is labeled with product information and handling instructions for easy identification and handling.
We offer various shipping methods for our customers to choose from, including air, sea, and land transportation. The shipping cost and delivery time will vary depending on the destination and chosen method. Our experienced logistics team will ensure prompt and safe delivery of the product to your desired location.
For international orders, we will handle all necessary customs documentation and procedures to facilitate smooth and efficient delivery. We also offer door-to-door delivery services for added convenience.
