| Place of Origin: | Made In China |
| Brand Name: | Infinity Machine |
| Certification: | CE ISO |
| Model Number: | IF3231 |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Clear sheet+sponge+wood carton |
| Delivery Time: | 20-30 days after order confirmed |
| Payment Terms: | TT PAYPAL Moneygram and so on |
| Supply Ability: | 200 sets / month |
| Features: | The Code Scanner Is Configured To Scan The QR Code Of The Product, Which Is More Convenient To Manage The Test Data Of The Corresponding Product. Real-time Display Of The Current Force Value And Displacement Changes, Can Be Displayed: Force-stroke (kgf-mm | Product Name: | Push And Pull Testing Machine |
|---|---|---|---|
| Host Size (WxDxH): | 1167x700x 1770mm | Speed Accuracy: | ±0.5% |
| Application: | The Equipment Is Used For All Kinds Of Electronic Components, Materials, Products For Stretching, Pressure Testing, So As To Determine Its Structural Resistance Strength. The Destructive Pressing Or Stretching Can Be Implemented, Automatically Judged And T | Effective Width: | 420mm |
| Force Value Sensor Capacity: | 500Kg | Displacement Measurement Accuracy: | ±0.05mm |
| Highlight: | IF3231 Push Pull Testing Machine,420mm Push And Pull Testing Machine |
||
One of the most prominent features of this machine is its high accuracy level. With a displacement decomposition degree of 0.001mm and force value accuracy of ±0.3%, this machine can provide precise and reliable test results. It can measure the tensile, compressive, and bending properties of materials with great accuracy.
The Push and Pull Testing machine is also known for its high testing speed. It can perform tests at a speed of 0~1000mm/min, making it ideal for testing materials that require high-speed testing. This feature ensures that the testing process is quick and efficient, allowing users to save time and increase productivity.
The Push and Pull Testing machine is powered by an AC220V 5A 50Hz power source, which ensures that it is capable of delivering consistent and reliable performance. Users can also specify the power source if required, making it a versatile machine that can be used in various settings.
The force value sensor capacity of the Push and Pull Testing machine is 500Kg. This means that it can measure the force applied to the material accurately, making it suitable for testing a wide range of materials such as metals, plastics, rubber, and textiles.
In summary, the Push and Pull Testing machine is an advanced testing machine that is highly accurate, fast, and versatile. It is ideal for measuring the mechanical properties of various materials and is widely used in various industries. Its high accuracy level, high testing speed, and reliable performance make it a valuable asset to any laboratory or research facility.
| Product Name: | Push and Pull Testing machine |
| Model: | IF3231 |
| Effective Width: | 420mm |
| Application: | The Equipment Is Used For All Kinds Of Electronic Components, Materials, Products For Stretching, Pressure Testing, So As To Determine Its Structural Resistance Strength. The Destructive Pressing Or Stretching Can Be Implemented, Automatically Judged And The Test Can Be Concluded After Rupture, Obtaining The Maximum Force Value And Displacement Of The Product. Constant Force Test Can Be Carried Out To Obtain The Life Of The Product Under A Certain Force. |
| Source: | AC220V 5A 50Hz Or Is Specified |
| Features: | The Code Scanner Is Configured To Scan The QR Code Of The Product, Which Is More Convenient To Manage The Test Data Of The Corresponding Product. Real-time Display Of The Current Force Value And Displacement Changes, Can Be Displayed: Force-stroke (kgf-mm), Or Force-time (kgf-time) Curve Diagram. The Test Report Can Be Selected, Directly Printed Or Saved As Word, Excel, PDF And Other Formats. The Motion Shaft Is Driven By Japanese Panasonic Servo Motor, Precision Ball Screw Drive, Low Noise, Durable Use. Language Has Simplified / Traditional / English Three Operation Interface Can Be Switched, The Force Value Unit Has N, Lb, Gf, Kgf Can Be Switched, Suitable For Global Customers. Configure The Manual X And Y Platforms To Change The Test Position Arbitrarily. Open Force Value Protection Function, A Protection Value Is Set According To The Conventional Test Force, When Operation Or Point Movement Will Automatically Stop Moving, To Reduce Damage To The Equipment And Precision Samples. The Floor Structure Design Of The Whole Machine Makes The Operator Closer To The Test Area And More Convenient For Sample Loading And Unloading. The Test Method Management Logic Is Clear, And The New Method Provides The Correctness Check Of The Parameters And Provides The Error Information. The Test Data Is Stored In A Local Database For Easy Access And Query. According To The Customer Agreement, It Has Data Upload Functions Such As Trace And PDCA. |
| Displacement Decomposition Degree: | 0.001mm |
| Machine Weight: | 185kg |
| Force Value Accuracy: | ±0.3% |
| Displacement Measurement Accuracy: | ±0.05mm |
Infinity Machine's IF3231 Push Tensile Testing Machine is a high-quality testing equipment that is made in China and certified with CE and ISO. The machine offers accurate force value measurement with a precision of ±0.3%, and displacement measurement accuracy of ±0.05mm. With a weight of 185kg, this testing machine can withstand heavy loads and is perfect for various testing scenarios.
The equipment is primarily used for all kinds of electronic components, materials, and products for stretching, pressure testing, so as to determine its structural resistance strength. The IF3231 is perfect for conducting destructive pressing or stretching tests, as it can automatically judge and conclude the test after rupture, obtaining the maximum force value and displacement of the product. Constant force tests can also be carried out to obtain the life of the product under a certain force.
The IF3231 Push Tensile Testing Machine is suitable for a wide range of applications in various industries, including but not limited to:
The IF3231 Push Tensile Testing Machine is also suitable for push and pull testing scenarios, making it a versatile and valuable tool for any laboratory or testing facility. The minimum order quantity for the IF3231 is 1, and the price is negotiable. The packaging details include clear sheet+sponge+wood carton, and the delivery time is 20-30 days after order confirmation. Payment terms include TT, PayPal, Moneygram, and other options, and the supply ability is 200 sets/month.
1. All test conditions are input by computer and automatically stored: load measurement range, stroke measurement range, total number of measurements, measurement speed, measurement direction, pause time, stay time, etc.
2. Plot of the conductive force-stroke (kgf-mm) and force-time (kgf-time).
3. Automatically calculate the maximum force value, maximum displacement, test time, product bar code information and so on.
4. The upper and lower limits can be set, and the Passed or Fail is automatically determined by the software.
Customize your Infinity Machine IF3231 Tensile Testing Machine to fit your specific needs!
Our product customization services include:
Our Tensile Testing Machine, also known as a Push and Pull Testing Machine, is perfect for all your stretching and pressure testing needs. Contact us to discuss your customization options!
Product Packaging:
Shipping:
Q1: What is the brand name of this testing machine?
A1: The brand name of this testing machine is Infinity Machine.
Q2: What is the model number of this testing machine?
A2: The model number of this testing machine is IF3231.
Q3: Where is this testing machine made?
A3: This testing machine is made in China.
Q4: What certifications does this testing machine have?
A4: This testing machine has CE and ISO certifications.
Q5: What is the minimum order quantity for this testing machine?
A5: The minimum order quantity for this testing machine is 1.
Q6: What is the price of this testing machine?
A6: The price of this testing machine is negotiable.
Q7: What are the packaging details for this testing machine?
A7: The packaging details for this testing machine include a clear sheet, sponge, and wood carton.
Q8: What is the delivery time for this testing machine?
A8: The delivery time for this testing machine is 20-30 days after order confirmed.
Q9: What payment terms are accepted for this testing machine?
A9: The accepted payment terms for this testing machine are TT, PayPal, Moneygram, and so on.
Q10: What is the supply ability for this testing machine?
A10: The supply ability for this testing machine is 200 sets per month.
