95% / -5% RH Salt Spray 35C For 30 Min Salt Fog Spray Corrosion Test Chamber

95% / -5% RH Salt Spray 35C For 30 Min Salt Fog Spray Corrosion Test Chamber   IE41

Product Description:

The Salt Spray Test Chamber (New) is a state-of-the-art equipment designed to simulate and accelerate the impact of salt pollution on metal materials. It is capable of creating an environment that can accelerate corrosion, allowing for efficient and accurate testing of the corrosion resistance of various metal materials. This equipment follows the test method of exposing the samples to a cycle of salt spray, dry, wet, and humid conditions. It is a comparative test, and the results cannot be used to predict the long-term corrosion resistance of the metal materials in the same environmental condition. However, it provides valuable information on the properties of materials exposed to salt-contaminated environments similar to the test conditions.

Compared to traditional accelerated corrosion tests, such as the Neutral Salt Spray Test (NSS), Acetate Salt Spray Test (AASS), and Copper Accelerated Acetate Salt Spray Test (CASS), the Salt Spray Test Chamber (New) offers more precise and efficient results.

Weight (Kg): Available in different weight options - About 300, About 400, About 500, About 600, and About 700.

Condenser mode: Air-cooled.

Equipment design principle: The equipment is designed to simulate and increase the impact of the environment on metal materials exposed to salt pollution and can accelerate corrosion.

Humidity range: 20~100%R.H.

Box structure: The Salt Spray Test Chamber (New) has a sturdy and durable box structure, consisting of the following components:

• Test Chamber Box: Made of PP polypropylene board with a thickness of 10mm, it has a temperature resistance of about 100 degrees. This box provides a controlled environment for the samples to be exposed to salt spray and other conditions.
• Laboratory Outer Box: Made of PP polypropylene board with a thickness of 10mm, it has a temperature resistance of about 100 degrees. This outer box provides additional protection and stability to the test chamber.
• Laboratory Sealing Cover: Made of PP polypropylene plate with a thickness of 10mm, this sealing cover has a one-button automatic open function and a transparent observation window. It also has a defogging device, allowing for clear observation of the test. This cover has a temperature resistance of about 100 degrees.

The Salt Spray Test Chamber (New) is a highly reliable and efficient equipment for testing the corrosion resistance of metal materials exposed to salt-contaminated environments. With its advanced design and precise testing methods, it provides valuable information for material selection and performance evaluation. Its sturdy box structure and temperature resistance make it a durable and long-lasting investment for any industry that deals with metal materials.

Applications:

Specification parameters:

model	I E4160L	I E4190L	I E41120L	I E41160L	I E41200L
Temperature range	5℃ ～ +85℃
Temperature departure	±1℃
Temperature fluctuation	±0.5℃
Temperature uniformity	≦2.0℃
Humidity range	20~100%R.H
Humidity deviation	±2%R.H
Relative humidity fluctuation	±2%R.H
Humidity uniformity	±3%R.H
Rising and cooling rate	RT →+85℃≤40 min RT→+0℃≤30 min Salt spray (35℃) dry (60℃.20~30%RH)≤30 min. Dry (60℃, 20-30% RH) and wet (50℃, 95% + / -5% RH) for 15 min. Moistet (50℃, 95% + / -5% RH) salt spray (35℃) for 30 min (immediate spray required after switching).
Effective inner capacity	150L	270L	576L	800L	1200L
Internal box size: WxHxD(mm )	600*500*500	900*600*600	1200*1000*600	1600*1000*600	2000*1000*600
Out box size: WxHxD(mm )	1780*950*1300	2080*1050*1350	2380*1450*1450	2780*1450*1450	3180*1450*1450
Box structure	● Test chamber box: using PP polypropylene board, the thickness of 10mm, temperature resistance of about 100 degrees. ● Laboratory outer box: using PP polypropylene board, thickness of 10mm, temperature resistance of about 100 degrees. ● Laboratory sealing cover: using PP polypropylene plate, thickness of 10mm, one-button automatic open cover, with transparent observation window, combined with the defogging device, Convenient clear observation of the test, temperature resistance of about 100 degrees.
Water filling method	Automatic / manual dual water supply mode, automatic water inlet with a set of water purifier
specimen holder	● The inner wall of PVC polyethylene dilute triangular tank box is used to place the dividing frame, the Angle of the test product can be adjusted at will, and the number of test pieces on all sides is completely consistent. ● At the bottom of the test box, the PP plate punching sample placement platform. The uniform opening on the platform surface will discharge the spray liquid quickly, and the large sample can be placed on the platform for testing.
refrigeration compressor	France taikang fully closed compressor
cooling medium	Non-fluorinated refrigerant R404A complies with environmental regulations, safe and non-toxic
Condenser mode	air-cooled
Safety protection device	refrigeration system	Compressor overheating protection Compressor overcurrent protection Over pressure and low pressure protection Condensate fan overheating protection
	test box	Adjustable overtemperature protection Extreme overtemperature protection of the air conditioning channel Fan, motor superheater relay protection
	heating system	Heating pipe dry burning protection alarm Abnormal water supply alarm Abnormal drainage alarm
	other	earth leakage protection Overload and short-circuit protection The power supply lacks the reverse phase protection function
weight (Kg)	About 300	About 400	About 500	About 600	About 700
source	AC380V;50Hz;7KW	AC380;V50Hz;9KW	AC380;V50Hz;11KW	AC 380;V50Hz;13KW	AC 380;V50Hz;15KW

Interface

The Salt Spray Test Chamber (New) by INFINITY is a highly reliable and efficient testing equipment designed for determining the corrosion resistance of materials and coatings. It is mainly used in industries such as automotive, aerospace, electronics, and coatings. The chamber is equipped with advanced features and technologies to provide accurate and consistent test results.

• Salt Spray Fog Test Chamber: The chamber is designed for performing salt spray fog tests to evaluate the corrosion resistance of materials and coatings.
• Salt Spray Corrosion Test Chamber: This chamber is suitable for conducting corrosion tests on various materials and coatings to determine their resistance against salt spray.

• Highly durable and temperature resistant box structure made of PP polypropylene boards.
• One-button automatic opening sealing cover with a transparent observation window and defogging device for easy and clear observation of the test.
• Fast rising and cooling rate for efficient testing.
• Equipped with a powerful refrigeration compressor from France Taikang for stable and consistent performance.
• Available in different sizes and power options to meet various testing requirements.
• Compliant with CE and ISO standards.

The Salt Spray Test Chamber (New) can be used in various industries and testing environments. Some common scenarios and applications include:

• Automotive Industry: The chamber is used for testing the corrosion resistance of automotive components and coatings.
• Aerospace Industry: It is used to evaluate the corrosion resistance of materials used in aircraft and spacecraft.
• Electronics Industry: The chamber is utilized to test the corrosion resistance of electronic components and coatings.
• Coatings Industry: Coating manufacturers use the chamber to determine the corrosion resistance of their products and make necessary improvements.

The price of the Salt Spray Test Chamber (New) by INFINITY is negotiable and can vary depending on the size and power options selected. Please contact us for a detailed quotation and to discuss your testing requirements.

The Salt Spray Test Chamber (New) by INFINITY is a versatile and reliable testing equipment that is widely used in various industries for evaluating the corrosion resistance of materials and coatings. It is equipped with advanced features and technologies to provide accurate and consistent test results. With a strong supply ability and a competitive price, this chamber is the perfect choice for your corrosion testing needs.
